Exuvia of Epiophlebiidae
Final renewal day of this page is February 7, 2005
English version Epiophlebiidae Egg-parasitoid wasp of Epiophlebia superstes Miscellany description of Epiophlebia superstes Egg of Epiophlebiidae Epiophlebia superstes 2
As for Epiophlebiidae 1 species of Epiophlebia superstes is inhabiting in Japan.
Epiophlebia superstes (Selys)
The size of the exuvia is 23-26 (25.3) mm. Head width: 6.1mm. Width of the abdomen: 6.7mm. The lateral spine is in 7-9 abdominal segments. The tip of the anal pyramid is not pointed. There is not a dorsal spine. There is a dark part in side of abdomen. There is such a file that emits sound there. When we touch the larva of Epiophlebia superstes they make small sound. The sound depends on this file.
| Figure EX6-1: Form |
|
|
|
Figure EX6-2 1:Labium 2:View from the under side of the abdomen |
 |
| Figure EX6-31: A part oｆ the labium An arrow is showing a movable hook 2:Antenna The antenna is 5 segments. 3:View from the back of the abdomen As for Epiophlebia superstes the anal pyramid (paraproct, epiproct) is short. And those are not sharp. |
 |
| Figure EX6-4:View from a side The number is showing the abdominal segment.A white arrow is showing the part of the file. The file is in 3-7 segments. The file of 3 segments is small. The file of 7 segments is only in the face of a side. |
 |
| Figure EX6-5 1: Files of 4,5,6 segments 2〜6:Forms of the files of 7 segments from 3 segments |
 |
